Name: Low Power Consumption Digital Pressure Controller / Digital Water Pressure Gauge
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KPG201
Price: 1,030.00 USD
Availability: InStock

خونه > محصولات > فشار سنج دیجیتال دقیق >

Low Power Consumption Digital Pressure Controller / Digital Water Pressure Gauge

stainless steel pressure gauge,submersible pressure sensor

submersible pressure sensor

Place of Origin:

China (Mainland)

نام تجاری:

Kacise

گواهی:

certificate of explosion-proof, CE

Model Number:

KPG201

با ما تماس بگیرید

درخواست نقل قول

Low Power Consumption Digital Pressure Controller / Digital Water Pressure Gauge

جزئیات محصول

Precision grade:

0.5%FS，0.4%FS ，0.2%FS，0.1%FS，0.05%FS

Pressure range:

-100kPa～0～600kPa～250MPa

Ambient temperature:

（-20～50）℃

Relative humidity:

＜95%

Atmospheric pressure:

（86～106）kPa

Storage temperature:

（-30～80）℃

Display:

SFTN liquid crystal display，White backlight，5 digit display.

Power supply mode:

4.2V rechargeable lithium battery

Installation method:

radial installation、axial belt mounting plate、Split type installation

برجسته کردن:

stainless steel pressure gauge,submersible pressure sensor

submersible pressure sensor

شرایط پرداخت و حمل و نقل

Minimum Order Quantity

1pcs

قیمت

قابل مذاکره

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal

Supply Ability

1000 Pieces per Week

محصولات مرتبط

ویدیو

KPG201C Touch Button No Mechanical Contact Digital Pressure Gauge With Data Logger

بهترین قیمت رو بدست بیار

ویدیو

Superior performance and high precision KPG201 Digital Pressure Gauge With Data Logger

بهترین قیمت رو بدست بیار

Digital water pressure gauge and data logger for pressure weight 0.6Kg with 4.2V rechargeable lithium battery

بهترین قیمت رو بدست بیار

Battery Powered Precision Digital Pressure Gauge Oxygen Pressure Gauge 0~400 bar

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86--17719566736

حالا تماس بگیرید

توضیحات محصول

Low Power Consumption Long Life Time Battery Powered USB Data Transfer Digital Manometer With Data Logger

Description

KPG201 precision digital pressure gauge is in accordance with the latest national standards developed and produced high-precision smart pressure measuring instruments. Pressure gauge mainly by the pressure sensor and signal processing circuit. Imported pressure sensor, superior performance, with high precision, corrosion resistance, shock resistance, vibration resistance, low temperature drift, high stability and other advantages; signal processing circuit using the latest ultra-low power processors, signal processing chips and power supply Management chip composition. High-capacity high-performance lithium battery-powered, no external power supply. The appearance of the instrument delicate, compact, beautiful, easy to use.

Features

• Wide temperature compensation, ultra-low power consumption.

• Unit changing, peak valley and other functions fully preserved.

• Multi additional setting and functions available, user can set by environment and habits.

• IP grade ≧ IP66, higher than the industry level.

Specification

Item	Spec.
Pressure range	-100kpa~250pa~5kpa~250Mpa
Accuracy	0.5%, 0.4%, 0.2%, 0.1%, 0.05%, 0.02%
Display	5-digit dynamic display + percentage indicator
Pressure unit	Pa, kPa, MPa, psi, bar, mbar, mmH2O, mmHg, inH2O, inHg, kgf/cm2
Overload pressure	150% FS
Destruction pressure	200% FS
Power supply	4.2V rechargeable lithium battery
Temperature	-20 ℃ ~ 60 ℃
Humidity	≤ 85% RH
Calibration environment	20 ℃ ± 2 ℃
Explosion-proof level	ExiaIICT4 optional
IP Grade	IP66
Data record limit	11000 (50000 Selective)
Process connection	M20 × 1.5 (male), special thread customizable
Dimensions	height 170mm, width 110mm, thickness 50mm
