KUFH2000B Portable Ultrasonic Flow Meter With Data Memory Function Non Intrusive Me with asuring with Consumption 1.5W

KUFH2000B Handheld Ultrasonic Flow Meter with Data Memory Function

1. Introduction

KUFH2000 handheld ultrasonic flow meter is ideal for flow surveys and closed pipe application where non-invasive measurement of liquids is required.
The advantages of high measurement accuracy, good consistency, battery power supply, easy operation and portability make this meter the smallest and lightest flow meter in domestic and a significant portable ultrasonic flow meter

2. Features

• High accuracy:Linearity: better than 0.5%, Repeatability: better than 0.2%, Accuracy:±1%
• Wide range of flow rate and pipe diameter:Suitable for the pipe with DN32 to DN6000
• Rechargeable power supply:Built-in NIMH rechargeable battery, which can support 12 hours of continuous work. When charging by power adapter, it can realize the uninterrupted measurement.
• Non-intrusive measuring:Non-intrusive, clamp-on transducer, no pressure drop, no pipe disturbance.
• Large LCD display:Display instantaneous flow, accumulated flow (positive, negative and net), velocity, working status etc.
• Built-in data logger:Built-in 24K data logger, store over 2000 lines measuring data

3. Installation

4. Sensor selection

Sensor selection depend on the application field parameters such as the diameter of the pipe the fix method
the kind of the flow, please refer to the fix method choice chapter for details.

5.Parameters

6. Ordering information
