Name: 0 - 500m Range Precision Pressure Sensor
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: GXPS140
Price: 152.00 USD
Availability: InStock

خونه > محصولات > سنسور فشار دقیق >

0 - 500m Range Precision Pressure Sensor

high accuracy pressure sensor,piezoresistive pressure transmitter

piezoresistive pressure transmitter

Place of Origin:

CHINA

نام تجاری:

KACISE

گواهی:

Model Number:

GXPS140

با ما تماس بگیرید

درخواست نقل قول

0 - 500m Range Precision Pressure Sensor

جزئیات محصول

Range:

0~500m

Accuracy:

±0.25%F.S, ±0.5%F.S, ±1.0%F.S

Output:

4-20mA, 0~5V, 1~5V, 0~10V

Material:

SS, 316L

temperature:

-40-160

thread:

G1/2

برجسته کردن:

high accuracy pressure sensor,piezoresistive pressure transmitter

piezoresistive pressure transmitter

شرایط پرداخت و حمل و نقل

Minimum Order Quantity

Delivery Time

3-8 working days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal

Supply Ability

1000000pcs/month

محصولات مرتبط

قطعات خودرو سنسور فشار تهویه مطبوع خودرو

بهترین قیمت رو بدست بیار

4-20mA خروجی مواد غذایی درجه بهداشت و بهداشت فلاش دیافراگم بهداشت و بهداشت فرستنده فشار صنعتی

بهترین قیمت رو بدست بیار

حسگر فشار آب مس 0.5-4.5 ولت با هزینه پایین برای گاز هوا صنعتی

بهترین قیمت رو بدست بیار

4-20mA HART خروجی Smart Double Flange Differential Level Pressure Transmitter برای صنایع صنعتی

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86--17719566736

حالا تماس بگیرید

توضیحات محصول

Kacise Hirsman connector high accuracy low cost OEM MEMS High Temperature Pressure Transducer preesure sensor

Introduction

GXPS140 micro pressure transducer uses micro machining technology to integrate piezoresis-sensitive element, and customer required micro package. The size and dimension could be designed to meet customer’s special requirement. Superiorities are: micro-shape, strong output signal, high temperature excellent dynamic and static character, reliable stability.

Application

Air dynamics research
Aircraft and Engine experiment
Wind tunnel experiment
fluid mechanics and hydraulic experiment
Biomedical application
Petroleum exploration and exploitation and so on

Feature of Piezoresistive mems pressure sensor for medical applications

MEMS sensor chip
Micro-structure, small volume, light weight
Excellent long-term stability
Wide measurement range, up to 100MPa
Strong output signal and anti-jamming capability
Excellent static and dynamic performance

Dimensions in mm

0 - 500m Range Precision Pressure Sensor 0

0 - 500m Range Precision Pressure Sensor 1

0 - 500m Range Precision Pressure Sensor 2

Specification of Piezoresistive mems pressure sensor for medical applications

Spec.	Value
Measurement Medium	Non-corrosive liquids that can compatible with silicon, stainless steel, glass, insulation adhesive or gas.
Pressure range	-100KPa～0～10KPa～1MPa～10MPa…100MPa
Accuracy	±0.2%F.S, ±0.5%F.S.
Power supply	0.5-2.0mA, 5-12VDC
Output signal	About 100mV
Transmitter output	Power: 24VDC(±15VDC), Output: 0-5VDC,4-20mA optional
Stability	±0.2%F.S/Year,
working temperature	-40～125℃ (High temperature with water-cooling structure can withstand 1200℃)
Response frequency	50-500KHZ
Insulation	≥500M Ω@100V
Overload pressure	200%FS
Rupture pressure	500%FS
Relative humidity	0%~95%
Electrical connection	Fixed cable, Aviation plug
Pressure port	M3, M4, M5, M6, M10 or others
Pressure type	Gauge, Sealed gauge, Absolute gauge,
IP rating	IP65

Ordering information

GXPS140- Pressure Type-Range –Accuracy-Pressure port-Electric connection- Signal output-working temperature- Power supply

Pressure Type: Gauge, Sealed gauge, Absolute gauge,
Range: -100KPa～0～10KPa～1MPa～10MPa…100MPa
Accuracy: 0.2%= 0.2%F.S., 0.5%= 0.5%F.S.
Pressure port: M3, M4, M5, M6, M10 or others
Electric connection: Fixed cable, Aviation plug
Signal output: 4~20mA, 0~5V, 1~5V, 0.5~4.5V, 0~10V or others
working temperature: -10～70℃, -25～85℃, -30～125℃, -45～150℃, -10～175℃ or other
Power supply: 5V, 10V, 24V(9-32V)

0 - 500m Range Precision Pressure Sensor 3

0 - 500m Range Precision Pressure Sensor 4

0 - 500m Range Precision Pressure Sensor 8
