Name: Digital Oil In Water Sensor For Surface Water Oil Field Testing With Measuring Range 0-500ppb
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KWS-1100
Availability: InStock

خونه > محصولات > سنسور کیفیت آب >

Digital Oil In Water Sensor For Surface Water Oil Field Testing With Measuring Range 0-500ppb

Fluorescence Method Oil In Water Sensor,Digital Oil In Water Sensor 500ppb,Oil In Water Detector 12v

Digital Oil In Water Sensor 500ppb

Oil In Water Detector 12v

Place of Origin:

Shaanxi, China

نام تجاری:

Kacise

گواهی:

Model Number:

KWS-1100

با ما تماس بگیرید

درخواست نقل قول

Digital Oil In Water Sensor For Surface Water Oil Field Testing With Measuring Range 0-500ppb

جزئیات محصول

principle:

fluorescence method

Measuring range:

0-500ppb

Accuracy:

±3%F.S

Power supply:

DC6-12V, current<50mA (when not cleaning)

Product Name:

KWS-1100 Online Oil-In-Water Sensor

Max. depth:

10m under water

Port:

Xi'an or other

برجسته کردن:

Fluorescence Method Oil In Water Sensor,Digital Oil In Water Sensor 500ppb,Oil In Water Detector 12v

Digital Oil In Water Sensor 500ppb

Oil In Water Detector 12v

شرایط پرداخت و حمل و نقل

Minimum Order Quantity

1pcs

قیمت

$100.00 - $1,000.00/pieces

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

T/T, Western Union, MoneyGram

Supply Ability

500 Piece/Pieces per Month

محصولات مرتبط

KCW102 دستگاه تصفیه آب با امواج الکترومغناطیسی با فرکانس پایین

بهترین قیمت رو بدست بیار

KCW101 فرکانس - تجهیزات تصفیه آب با امواج الکترومغناطیسی مدول

بهترین قیمت رو بدست بیار

KHM100 کنترل کیفیت آب متریال سنگین اتوماتیک

بهترین قیمت رو بدست بیار

KCW104 فرکانس کارایی بالا - دستگاه پاک کننده

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86--17719566736

حالا تماس بگیرید

توضیحات محصول

Digital Oil in water sensor for surface water oil field testing

Kacise online water sensor uses the principle of fluorescence. Compared with several commonly used methods, the fluorescence method is more efficient and quicker, and can be monitored online in real time. The sensor has better repeatability and stability. Optional with an automatic cleaning brush, it eliminates air bubbles, reduces the effects of contamination on the measurement, makes the maintenance cycle longer, and maintains excellent stability for long-term online use. It can play an early warning role on oil pollution in water.

Principle

The oil content in the water body was monitored by ultraviolet fluorescence method, and the oil concentration in the water body was quantitatively analyzed according to the fluorescence intensity of the oil and its aromatic hydrocarbon compound and the conjugated double bond compound absorbing ultraviolet light. The aromatic hydrocarbons in the petroleum form fluorescence under the excitation of ultraviolet light, and the value of the oil in the water is calculated according to the intensity of the fluorescence.

Feature

Digital sensor, RS-485 output, support MODBUS
Optional automatic cleaning brush to eliminate the impact of oil on the measurement
Eliminate the impact of ambient light on measurements with unique optical and electronic filtering techniques
It is not affected by suspended solids in water.

Technical Specifications

Model	KWS-1100
Measuring Range	0-1100ppb(BTEX),0-1000ppb(PAH)
Principle	fluorescence method
Resolution	0.01ppb
The detection limit	1ppb
Linearity	R²>0.999 (standard liquid continuous dilution)
IP Grade	IP68
Max. Pressure	3 bar
Temperature Range	0~50℃
Output	RS485, Modbus
Installation	Submersible (NPT3/4 thread)
Power Supply	DC12-24V, current＞1A
Consumption	0.25W/0.8W when self-cleaning
Calibration	0, 1 or 2 point calibration
Cable Length	Standard 10m, customizable
Casing Material	316L (titanium alloy customizable)
