Name: Support MODBUS and RS-485 output digital oil in water sensors support MODBUS and CE certification with resolution 0.1pp
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KBU601
Price: 5,000.00 USD
Availability: InStock

خونه > محصولات > سنسور کیفیت آب >

Support MODBUS and RS-485 output digital oil in water sensors support MODBUS and CE certification with resolution 0.1pp

water turbidity sensor,oil in water sensor

oil in water sensor

Place of Origin:

Shaanxi, China (Mainland)

نام تجاری:

KACISE

گواهی:

CE,ISO

Model Number:

KBU601

با ما تماس بگیرید

درخواست نقل قول

Support MODBUS and RS-485 output digital oil in water sensors support MODBUS and CE certification with resolution 0.1pp

جزئیات محصول

Measuring range:

0-500ppb or 0-5000ppb

Resolution:

0.1ppb

accurate:

Protection level:

IP68

temperature range:

0 ~ 50℃

product material:

POM

برجسته کردن:

water turbidity sensor,oil in water sensor

oil in water sensor

شرایط پرداخت و حمل و نقل

Minimum Order Quantity

0-100

قیمت

قابل مذاکره

Packaging Details

carton or customers requests available

Delivery Time

5 working days after payment

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100

محصولات مرتبط

KCW102 دستگاه تصفیه آب با امواج الکترومغناطیسی با فرکانس پایین

بهترین قیمت رو بدست بیار

KCW101 فرکانس - تجهیزات تصفیه آب با امواج الکترومغناطیسی مدول

بهترین قیمت رو بدست بیار

KHM100 کنترل کیفیت آب متریال سنگین اتوماتیک

بهترین قیمت رو بدست بیار

KCW104 فرکانس کارایی بالا - دستگاه پاک کننده

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86--17719566736

حالا تماس بگیرید

توضیحات محصول

Online oil-in-water sensor

Feature

Digital sensor, RS-485 output, support MODBUS. Optional automatic cleaning brush to eliminate the impact of oil on the measurement, this product uses a unique optical and electronic filtering technology to eliminate the impact of ambient light on the measurement, not affected by suspended solids.

Applications

The oil sensor in the water uses the principle of ultraviolet fluorescence analysis and has high sensitivity for detecting soluble and emulsifiable oil. were able Use a self-cleaning brush to effectively eliminate the effect of oil on the measurement. Suitable for oil field monitoring, industrial circulating water, condensed water, wastewater treatment,

Various water quality monitoring programs, such as surface water stations.

Technical Specifications

product	oil-in-water sensor	Self-cleaning oil-in-water sensor
principle	Ultraviolet fluorescence method
Measuring range	0-500ppb or 0-5000ppb
Resolution	0.1ppb
accurate	5%
Protection level	IP68
Deepest depth	Underwater 60 meters	underwater 10 meters
temperature range	0 ~ 50℃
Output	Support RS-485, MODBUS protocol
Power supply	DC 5~12V, current <50mA	DC 5~12V, current <50mA (when not cleaned)
size	Φ22mm*120mm	Φ33mm*156mm
Probe cable length	10 m, customizable 5 m, 15 m and 30 m cable
product material	POM
Self-cleaning system	exist	No
Optical window	optical fiber

Company Information

Support MODBUS and RS-485 output digital oil in water sensors support MODBUS and CE certification with resolution 0.1pp 0

Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards.

We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.

Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.
