Accurate Water Quality Sensor Digital Conductivity Sensor Support Modbus With 5m Cable

water turbidity sensor,oil in water sensor

oil in water sensor

Place of Origin:

China (Mainland)

نام تجاری:

Kacise

گواهی:

certificate of explosion-proof, CE

Model Number:

KWS-300

با ما تماس بگیرید

درخواست نقل قول

Accurate Water Quality Sensor Digital Conductivity Sensor Support Modbus With 5m Cable

جزئیات محصول

Response Time:

＜10s

Max. Pressure:

6 bar

Output:

RS485 Modbus

Power Supply:

DC9 -24V, ≥1A

Sensor Dimension:

φ22mm*175.5mm

Protection level:

IP68

برجسته کردن:

water turbidity sensor,oil in water sensor

oil in water sensor

شرایط پرداخت و حمل و نقل

Minimum Order Quantity

0-100

قیمت

USD300-USD1000

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 working days

Payment Terms

Western Union, MoneyGram, T/T

Supply Ability

100

محصولات مرتبط

KCW102 دستگاه تصفیه آب با امواج الکترومغناطیسی با فرکانس پایین

بهترین قیمت رو بدست بیار

KCW101 فرکانس - تجهیزات تصفیه آب با امواج الکترومغناطیسی مدول

بهترین قیمت رو بدست بیار

KHM100 کنترل کیفیت آب متریال سنگین اتوماتیک

بهترین قیمت رو بدست بیار

KCW104 فرکانس کارایی بالا - دستگاه پاک کننده

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86--17719566736

حالا تماس بگیرید

توضیحات محصول

Conductivity Salt Sensor Water Qualtiy Sensor of RS458 Output digital conductivity sensor support Modbus with 5m cable

Name: Accurate Water Quality Sensor Digital Conductivity Sensor Support Modbus With 5m Cable
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KWS-300
Price: 650.00 USD
Availability: InStock

1. Applications

Kacise introduces a new generation of four-electrode conductivity sensor, adopts international leading four-electrode technology, RS485 digital interface, supports MODBUS protocol, and environmentally friendly design. Compared with the traditional two-electrode conductivity sensor, it has higher accuracy, wider measurement range and excellent stability. The four-electrode conductivity sensor also has a unique advantage in quantity: one is to completely solve the polarization problem in high conductivity test; the other is to solve the problem of inaccurate reading caused by electrode contamination

2. Feature

Digital sensor, RS-485 output, support MODBUS.
Wide range, automatic switching measuring range.

3.Technical Specifications

Item	Conductivity Sensor	Salinity Sensor
Model	KWS-300	KWS-310
Range	0.01-5mS/cm or 0.01-100 mS/cm	0-2.5ppt or 0-80ppt
Accuracy	＜±1% or 0.01mS/cm	±0.05ppt or ±1ppt
Response Time	＜10s
Ip Grade	IP68
Max. Pressure	6 bar
Electrode Material	Nickel+PEEK
Sheath Material	Titanium
Operating Temperature	0~50℃(no freezing)
Output	RS485, Modbus
Power Supply	DC9 -24V, ≥1A
Sensor Dimension	φ22mm*175.5mm
Cable Length	10 meters (default), customizable
Calibration	support one point or two-points calibration

4.Dimensions

Accurate Water Quality Sensor Digital Conductivity Sensor Support Modbus With 5m Cable 0

5.Company Information

Accurate Water Quality Sensor Digital Conductivity Sensor Support Modbus With 5m Cable 1

Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards.

We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.

Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.

Accurate Water Quality Sensor Digital Conductivity Sensor Support Modbus With 5m Cable 2

Accurate Water Quality Sensor Digital Conductivity Sensor Support Modbus With 5m Cable 3
