KEC601 0.6MPa Water Quality Monitoring Sensors 3/4 NPT Thread

0.6MPa water quality monitoring sensors,3/4 NPT thread water monitoring sensors,24VDC water quality monitoring sensors

3/4 NPT thread water monitoring sensors

24VDC water quality monitoring sensors

Place of Origin:

CHINA

نام تجاری:

kacise

گواهی:

Model Number:

KCD602

با ما تماس بگیرید

درخواست نقل قول

KEC601 0.6MPa Water Quality Monitoring Sensors 3/4 NPT Thread

جزئیات محصول

Measuring range:

0～5000μS/cm

water quality monitor Conductivity Resolution:

1μS/cm

water quality monitor Conductivity Precision:

±1.5%F.S.

Working Temperature:

0～65℃

Power Supply:

12～24VDC ±10%

Signal Output:

RS-485(Modbus/RTU)

Wetted Material:

ABS/SUS316L(Default）/PVC customized

برجسته کردن:

0.6MPa water quality monitoring sensors,3/4 NPT thread water monitoring sensors,24VDC water quality monitoring sensors

3/4 NPT thread water monitoring sensors

24VDC water quality monitoring sensors

شرایط پرداخت و حمل و نقل

Minimum Order Quantity

0-100

قیمت

$0-$1500

Packaging Details

Common package or custom package

Delivery Time

3-10days

Payment Terms

D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100

محصولات مرتبط

KCW102 دستگاه تصفیه آب با امواج الکترومغناطیسی با فرکانس پایین

بهترین قیمت رو بدست بیار

KCW101 فرکانس - تجهیزات تصفیه آب با امواج الکترومغناطیسی مدول

بهترین قیمت رو بدست بیار

KHM100 کنترل کیفیت آب متریال سنگین اتوماتیک

بهترین قیمت رو بدست بیار

KCW104 فرکانس کارایی بالا - دستگاه پاک کننده

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86--17719566736

حالا تماس بگیرید

توضیحات محصول

KEC601 Small Outline Online Water Quality Monitor Conductivity Sensor For Drinking Water Surface Water Various Water

1.Application Environment

Drinking water / surface water / various water supply / industrial water treatment.
Signal output: RS-485 (Modbus/RTU protocol).
Convenient connection to third-party equipment such as PLC, DCS, industrial control computer, general controller, paperless recording instrument or touch screen.
Immersion installation with 3/4 NPT pipe thread for easy submersible installation or installation in pipes and tanks.
IP68 protection grade.

2.Technical Specifications

Model	KEC601
Measuring range	0～5000μS/cm
Resolution	1μS/cm
Precision	±1.5%F.S.
Working Temperature	0～65℃
Working Pressure	＜0.6MPa
Power Supply	12～24VDC ±10%
Signal Output	RS-485(Modbus/RTU)
Wetted Material	ABS/SUS316L(Default)/PVC
Mounting Method	Immersion mounting, 3/4 NPT thread
Cable Length	5 meters, other lengths can be customized
Temperature Compensation	Auto temperature compensation(Pt1000)
Calibration	Two-point calibration
Power Consumption	＜0.3W@12V
Protection Grade	IP68

3.Dimensional Drawing

KEC601 0.6MPa Water Quality Monitoring Sensors 3/4 NPT Thread 0

4.Installation and Electrical Connection

4.1 Installation

KEC601 0.6MPa Water Quality Monitoring Sensors 3/4 NPT Thread 1

Note: At least 2 cm from the bottom and side walls of the container during installing and testing.

4.2 Electrical Connection

a) Red line - power cord (12 ~ 24V)

b) Black line - ground (GND)

c) Blue line - 485A

d) white line - 485B

e) bare wire - shielded wire

After wiring is completed, it should be carefully checked to avoid incorrect connections before powering up.

Cable specification: Considering that the cable is immersed in water (including sea water) for a long time or exposed to the air, the cable has certain corrosion resistance. The outer diameter of the cable is Φ6 mm and all interfaces are waterproof.
