Name: KL Series Load Cell Sensor Multiple Models 5 - 15V
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: GXLC-DZ-0.5T
Price: 50 USD
Availability: InStock

خونه > محصولات > سنسور لودسل >

KL Series Load Cell Sensor Multiple Models 5 - 15V

15V Load Cell Sensor,300kg Load Cell Sensor,KL Load Cell Weight Sensor

300kg Load Cell Sensor

KL Load Cell Weight Sensor

Place of Origin:

China

نام تجاری:

Kacise

Model Number:

GXLC-DZ-0.5T

با ما تماس بگیرید

درخواست نقل قول

KL Series Load Cell Sensor Multiple Models 5 - 15V

جزئیات محصول

Capacity:

300kg

Rated output:

1.2±10%mV/V

Zero balance:

±1%F.S.

impedance:

700/1400ohm

Ultimate overload:

200%F.S

Safe overload:

150%F.S

Operation temp range:

-20~80 ℃

Recommended excitation:

5~15V

برجسته کردن:

15V Load Cell Sensor,300kg Load Cell Sensor,KL Load Cell Weight Sensor

300kg Load Cell Sensor

KL Load Cell Weight Sensor

شرایط پرداخت و حمل و نقل

Minimum Order Quantity

قیمت

50USD/pc

Packaging Details

carton

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100+

محصولات مرتبط

Weighbridge 5kg Electronic Strain Gauge Load Cell

بهترین قیمت رو بدست بیار

Waterproof Round Load Cell Transmitter

بهترین قیمت رو بدست بیار

0.5kg 1kg 2kg 3kg Stainless Steel Small Load Cell Sensor

بهترین قیمت رو بدست بیار

Impact S - Beam Crane Scale Load Cell Sensor Strain Gauge High Precision

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

حالا تماس بگیرید

توضیحات محصول

GXLC-DZ-0.3T Load Cell

Specification

Item	Parameters
Capacity	300kg
Rated output	1.2±10%mV/V
Zero balance	±1%F.S.
Non-linearity	0.05%F.S
Hysteresis	0.05%F.S
Repeatability	0.03%F.S
Creep (30min)	0.03%F.S
Temp.effect on output	0.03%F.S/10 ℃
Temp.effect on zero	0.03%F.S/10 ℃
impedance	700/1400ohm
Insulation	≥5000M ohm/100VDC
Recommended excitation	5~15V
Operation temp range	-20~80 ℃
Safe overload	150%F.S
Ultimate overload	200%F.S
Cable size	Φ5x3000mm
